Here is a checklist to copy a Dynamics 365 for Finance and operations database in from a tier-2 (or above) to a OneBox (Dev, Build or Test).

1. Start by creating a new database as a copy of the original (since you are going to mess with it) by running this SQL query:

   CREATE DATABASE MyNewCopy AS COPY OF axdb_mySourceDatabaseToCopy

   Since this operation runs asynchronously in the background you will have to keep an eye on it before continuing:

   SELECT * FROM sys.dm_database_copies

2. Prepare the database for export

   --Prepare a database in Azure SQL Database for export to SQL Server.
   --Disable change tracking on tables where it is enabled.
   declare
   @SQL varchar(1000)
   set quoted_identifier off
   declare changeTrackingCursor CURSOR for
   select 'ALTER TABLE ' + t.name + ' DISABLE CHANGE_TRACKING'
   from sys.change_tracking_tables c, sys.tables t
   where t.object_id = c.object_id
   OPEN changeTrackingCursor
   FETCH changeTrackingCursor into @SQL
   WHILE @@Fetch_Status = 0
   BEGIN
   exec(@SQL)
   FETCH changeTrackingCursor into @SQL
   END
   CLOSE changeTrackingCursor
   DEALLOCATE changeTrackingCursor

   --Disable change tracking on the database itself.
   ALTER DATABASE
   -- SET THE NAME OF YOUR DATABASE BELOW
   MyNewCopy
   set CHANGE_TRACKING = OFF
   --Remove the database level users from the database
   --these will be recreated after importing in SQL Server.
   declare
   @userSQL varchar(1000)
   set quoted_identifier off
   declare userCursor CURSOR for
   select 'DROP USER [' + name + ']'
   from sys.sysusers
   where issqlrole = 0 and hasdbaccess = 1 and name <> 'dbo'
   OPEN userCursor
   FETCH userCursor into @userSQL
   WHILE @@Fetch_Status = 0
   BEGIN
   exec(@userSQL)
   FETCH userCursor into @userSQL
   END
   CLOSE userCursor
   DEALLOCATE userCursor
   --Delete the SYSSQLRESOURCESTATSVIEW view as it has an Azure-specific definition in it.
   --We will run db synch later to recreate the correct view for SQL Server.
   if(1=(select 1 from sys.views where name = 'SYSSQLRESOURCESTATSVIEW'))
   DROP VIEW SYSSQLRESOURCESTATSVIEW
   --Next, set system parameters ready for being a SQL Server Database.
   update sysglobalconfiguration
   set value = 'SQLSERVER'
   where name = 'BACKENDDB'
   update sysglobalconfiguration
   set value = 0
   where name = 'TEMPTABLEINAXDB'
   --Clean up the batch server configuration, server sessions, and printers from the previous environment.
   TRUNCATE TABLE SYSSERVERCONFIG
   TRUNCATE TABLE SYSSERVERSESSIONS
   TRUNCATE TABLE SYSCORPNETPRINTERS
   --Remove records which could lead to accidentally sending an email externally.
   UPDATE SysEmailParameters
   SET SMTPRELAYSERVERNAME = ''
   GO
   UPDATE LogisticsElectronicAddress
   SET LOCATOR = ''
   WHERE Locator LIKE '%@%'
   GO
   TRUNCATE TABLE PrintMgmtSettings
   TRUNCATE TABLE PrintMgmtDocInstance
   --Set any waiting, executing, ready, or canceling batches to withhold.
   UPDATE BatchJob
   SET STATUS = 0
   WHERE STATUS IN (1,2,5,7)
   GO
   -- Clear encrypted hardware profile merchand properties
   update dbo.RETAILHARDWAREPROFILE set SECUREMERCHANTPROPERTIES = null where SECUREMERCHANTPROPERTIES is not null

   Remember to change the database namn on line 23

3. Export the database

   cd C:\Program Files (x86)\Microsoft SQL Server\140\DAC\bin

   SqlPackage.exe /a:export /ssn:<server>.database.windows.net /sdn:MyNewCopy /tf:D:\Exportedbacpac\my.bacpac /p:CommandTimeout=1200 /p:VerifyFullTextDocumentTypesSupported=false /sp:<SQLAdmin password> /su:sqladmin

   Note: I usually store the DB backup in an Azure Storage Blog since this is the easiest way to move file between environments. See here

4. Import the backup in the target environment

   cd C:\Program Files (x86)\Microsoft SQL Server\140\DAC\bin

   SqlPackage.exe /a:import /sf:D:\Exportedbacpac\my.bacpac /tsn:localhost /tdn:<target database name> /p:CommandTimeout=1200



5. When the database is imported you will need to prepare it for the new environment

   CREATE USER axdeployuser FROM LOGIN axdeployuser
   EXEC sp_addrolemember 'db_owner', 'axdeployuser'

   CREATE USER axdbadmin FROM LOGIN axdbadmin
   EXEC sp_addrolemember 'db_owner', 'axdbadmin'

   CREATE USER axmrruntimeuser FROM LOGIN axmrruntimeuser
   EXEC sp_addrolemember 'db_datareader', 'axmrruntimeuser'
   EXEC sp_addrolemember 'db_datawriter', 'axmrruntimeuser'

   CREATE USER axretaildatasyncuser FROM LOGIN axretaildatasyncuser
   EXEC sp_addrolemember 'DataSyncUsersRole', 'axretaildatasyncuser'

   CREATE USER axretailruntimeuser FROM LOGIN axretailruntimeuser
   EXEC sp_addrolemember 'UsersRole', 'axretailruntimeuser'
   EXEC sp_addrolemember 'ReportUsersRole', 'axretailruntimeuser'

   CREATE USER axdeployextuser FROM LOGIN axdeployextuser
   EXEC sp_addrolemember 'DeployExtensibilityRole', 'axdeployextuser'

   CREATE USER [NT AUTHORITY\NETWORK SERVICE] FROM LOGIN [NT AUTHORITY\NETWORK SERVICE]
   EXEC sp_addrolemember 'db_owner', 'NT AUTHORITY\NETWORK SERVICE'

   UPDATE T1
   SET T1.storageproviderid = 0
       , T1.accessinformation = ''
       , T1.modifiedby = 'Admin'
       , T1.modifieddatetime = getdate()
   FROM docuvalue T1
   WHERE T1.storageproviderid = 1 --Azure storage

   ALTER DATABASE [<your AX database name>] SET CHANGE_TRACKING = ON (CHANGE_RETENTION = 6 DAYS, AUTO_CLEANUP = ON)
   GO
   DROP PROCEDURE IF EXISTS SP_ConfigureTablesForChangeTracking
   DROP PROCEDURE IF EXISTS SP_ConfigureTablesForChangeTracking_V2
   GO
   -- Begin Refresh Retail FullText Catalogs
   DECLARE @RFTXNAME NVARCHAR(MAX);
   DECLARE @RFTXSQL NVARCHAR(MAX);
   DECLARE retail_ftx CURSOR FOR
   SELECT OBJECT_SCHEMA_NAME(object_id) + '.' + OBJECT_NAME(object_id) fullname FROM SYS.FULLTEXT_INDEXES
   	WHERE FULLTEXT_CATALOG_ID = (SELECT TOP 1 FULLTEXT_CATALOG_ID FROM SYS.FULLTEXT_CATALOGS WHERE NAME = 'COMMERCEFULLTEXTCATALOG');
   OPEN retail_ftx;
   FETCH NEXT FROM retail_ftx INTO @RFTXNAME;

   BEGIN TRY
   	WHILE @@FETCH_STATUS = 0
   	BEGIN
   		PRINT 'Refreshing Full Text Index ' + @RFTXNAME;
   		EXEC SP_FULLTEXT_TABLE @RFTXNAME, 'activate';
   		SET @RFTXSQL = 'ALTER FULLTEXT INDEX ON ' + @RFTXNAME + ' START FULL POPULATION';
   		EXEC SP_EXECUTESQL @RFTXSQL;
   		FETCH NEXT FROM retail_ftx INTO @RFTXNAME;
   	END
   END TRY
   BEGIN CATCH
   	PRINT error_message()
   END CATCH

   CLOSE retail_ftx;
   DEALLOCATE retail_ftx;
   -- End Refresh Retail FullText Catalogs

6. Switch to using the new database
7. Stop these services
   World Wide Web Publishing Service
   Management Reporter 2012 Process Service
   Microsoft Dynamics 365 Unified Operations: Batch Management Service
8. Rename the old database to AxDB_orig
9. Rename the new database to AxDB
10. Start these services
    World Wide Web Publishing Service
    Microsoft Dynamics 365 Unified Operations: Batch Management Service
    Management Reporter 2012 Process Service
11. Synchronize the database from Visual Studio

Links
https://docs.microsoft.com/en-us/dynamics365/unified-operations/dev-itpro/database/copy-database-from-azure-sql-to-sql-server
