The Real-Time Service call Failed when trying to use CloudPoS

One of my colleagues contacted me today about an issue. When he was logged into the Dynamics 365 for Operations  Cloud POS and he tried to perform a “Real-Time Operation” such as resetting a password he got this error:

4BF47ABA

To reproduce it I tried to do the same, and low and behold it worked… we used the same PoS worker and we had the same Roles in Dynamics…

While he was doing some more testing i logged in to the Dynamics Server using RDP to see if there was anything in the Event viewer… Found something!

Real-time Service client library call for API ‘InvokeMethod’ method ‘UpdateStaffPassword’, language ‘sv-SE’, and company ‘usrt’ failed. Exception: ‘System.ServiceModel.FaultException`1[Microsoft.Dynamics.Retail.TransactionServices.ClientProxy.Fault]: Fault was thrown by the service for request c7f48632-52a9-447e-ba42-9d7cb4c800ba. Exception details:
Type: Microsoft.Dynamics.Ax.Xpp.ErrorException

Message: The language sv-SE is not supported by Microsoft Dynamics 365 for Operations
. For a list of supported languages, see Microsoft Dynamics 365 for Operations Online. (Fault Detail is equal to Microsoft.Dynamics.Retail.TransactionServices.ClientProxy.Fault).’.

The language sv-SE is not supported by Dynamics 365 for Operations… that’s better… now I know where to look. My browser was using english and my colleague was using swedish. We changed it to look like this by switching the order and moving English to the top…


… it worked !!!

That is all for today

/Johan

Activating Dynamincs AX 2012 VMs deployed to Azure from LCS

Our company has retired all of our lab hosts which we used to have internally which means thet we need to have our lab servers on Microsoft Azure. To install the servers we use LCS (Lice Cycle Services) which deploys a VM in our Azure Subscription. The problem is that the VM is not activated, which on an internal server would require a product key and a Windows Server License… When running VMs internally we used to handle this by rearming the VMs 3 times which gives us a total of 180 days and then set up a new one which was a little hassle but it worked. But since we now have deployed VMs on Azure there is actually a license included in the Azure VM which means that there is no need to run a server which is not activated. Here is a short description on how to activate the AX VM…

  1. Install the new VM on Microsoft Azure using LCS
  2. Log into the the server using RDP (the logon info is in LCS)
  3. Start an elevated command prompt
  4. Find the edition of the VM by running this command:

    DISM /online /Get-CurrentEdition

    We get: Current Edition : ServerDatacenterEval

  5. Find out which edition you can upgrade to by running:

    DISM /online /Get-TargetEditions

    We get: Target Edition : ServerDatacenter

    This means that you can upgrade from the evaluation edition of datacenter edition to the full version of datacenter edition. Now we need a license key… Microsoft uses Automatic Virtual Machine Activation to license the VMs in Azure… This means that if the host is activated (which it hopefully is Smile ) the guest gets activated but to use this feature the guest VM still need a product key. The keys are available on Technet.

  6. Use the correct key to activate the VM by running this:

    DISM /online /Set-Edition:ServerDatacenter /ProductKey:XXXXX-XXXXX-XXXXX-XXXXX-XXXXX /AcceptEULA

  7. Restart the VM and verify that is is not using Evaluation Edition anymore


That’s all for today

Links:

https://technet.microsoft.com/en-us/library/dn303421.aspx

Issues with Retail Layout designer

One of my colleagues had an issue accessing the Screen Layout designer in the AX Client and I was a bit confused… it worked for me… This turned out to be two separate issues.

image    image

The first one was that he and I was logged into two different AOSes and the Retail Headquarter was not installed on the one he was logged on to… simple enough to fix… I simply installed it. The Retail Headquarter component includes some DLLS that are required. If you want to be able to run the Retail Layout Designer on a  client or terminal server you will need to install the retail components on the client/terminal server as well.

When we installed the Headquarter components we unfortunately missed the fact the we “probably should” install Expression Blend Sad smile (note to self… read all the instructions)


When we tried to start the Designer it crashed with this error.


I found information on this issue on LCS Issue Search (Link below). The trick is to install Expression Blend Dev Kit for .NET and then copy Microsoft.Expression.Interactions.dll and System.Windows.Interactivity.dll from “C:\Program Files (x86)\Microsoft SDKs\Expression\Blend\.NETFramework\v4.0\Libraries” to “C:\Program Files (x86)\Microsoft Dynamics AX\60\Client\Bin”

When these issues was fixed and my colleague tried to start the Button Grid Layout he gets this error:

SNAGHTML54766cd

Normally the AX AOS Service user is used to access the AX database but in some cases the individual user needs to have specific access… below is a link to an article that describes steps involved



Links
https://fix.lcs.dynamics.com/Issue/Solution/1223064?bugId=3725829&qc=dd5219a830d7a93c687ff03083b2970a6ae1775a018daa69b8be820ab77ae101

http://daxdude.blogspot.se/2013/02/ax-issue-method-start-in-com-object-of.html

Email errors in AX 2012 R2

One of my customers have migrated to new servers for their AOSes, these are brand new Windoews Server 2012 R2 servers… nice. We hade one issue though… When trying to send emails using batch from a batch jog we got the following error:

Microsoft.Dynamics.Ax.Xpp.ClrErrorException: Exception of type ‘Microsoft.Dynamics.Ax.Xpp.ClrErrorException’ was thrown.

   at Microsoft.Dynamics.Ax.Xpp.CLRInterop.staticInvoke(String typeName, String methodName, Object[] parameters, Type type)

   at Dynamics.Ax.Application.WinAPIServer.cryptUnProtectData(Object[] _encryptedDataBlob) in WinAPIServer.cryptUnProtectData.xpp:line 39

   at Dynamics.Ax.Application.SysEmailParameters.password() in SysEmailParameters.password.xpp:line 18

   at Dynamics.Ax.Application.SysEmailDistributor.Processemails(Guid _emailProcessorId) in SysEmailDistributor.processEmails.xpp:line 39

   at Dynamics.Ax.Application.SysEmailDistributor.Run() in SysEmailDistributor.run.xpp:line 78

   at Dynamics.Ax.Application.BatchRun.runJobStaticCode(Int64 batchId) in BatchRun.runJobStaticCode.xpp:line 54

   at Dynamics.Ax.Application.BatchRun.runJobStatic(Int64 batchId) in BatchRun.runJobStatic.xpp:line 13

   at BatchRun::runJobStatic(Object[] )

   at Microsoft.Dynamics.Ax.Xpp.ReflectionCallHelper.MakeStaticCall(Type type, String MethodName, Object[] parameters)

   at BatchIL.taskThreadEntry(Object threadArg)

It took me some time to figure it out… Apparently the password for the SMTP account is saved in the AX database, but using an encryption key from the computer which saved it (a.k.a. the server that was retired) so when moving to the new server it was not able to read it. To fix it I simply entered the password again from the new server and Presto!

/JP

The given value of type String from the data source cannot be converted to type nvarchar of the specified target column when syncing Retail Data to Channel Database

One of our customer are going to use the AX 2012 R3 Retail solution and the setup of the Async Server – Client in the TEST environment was setup and tested. The application consultants started importing the product data to AX and suddenly the sync stopped with this error:

Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.ProcessSourceRequestHeaderException: ProcessTargetRequestHeader failed due to an InvalidOperationException.connectionString: Data Source=XXXXXX;Initial Catalog=ClientChannelDB;Integrated Security=True;Connect Timeout=60;Application Name=”Commerce Data Exchange Async Client” —> System.InvalidOperationException: The given value of type String from the data source cannot be converted to type nvarchar of the specified target column. —> System.InvalidOperationException: String or binary data would be truncated.

After having a look online I found that there is no sync of the schema between the AX database and the Channel Database (!!!). This meant that when we imported data to AX everything worked but when we did the sync jobs it failed. The reason being that some field types did not match.

After talking to MS support I got a script to try to figure out which fields were wrong

select t1.table_name, t1.column_name, t1.character_maximum_length, t2.character_maximum_length
from MicrosoftDynamicsAX.INFORMATION_SCHEMA.columns t1
inner join RetailHoustonStore.INFORMATION_SCHEMA.columns t2
on t1.table_name = t2.table_name
and t1.column_name = t2.column_name
and t1.character_maximum_length != t2.character_maximum_length order by TABLE_NAME

this query finds all of the fields which are not matched between the AX database and the Channel Database. With some help we found that the issue probably was the field called RETAILVARIANTID which was present in INVENTDIMCOMBINATION and INVENTITEMBARCODE

We ran these SQL queries:

ALTER TABLE [ClientChannelDB].ax.INVENTDIMCOMBINATION ALTER COLUMN RETAILVARIANTID nvarchar(25) NOT NULL;
ALTER TABLE [ClientChannelDB].ax.INVENTITEMBARCODE ALTER COLUMN RETAILVARIANTID nvarchar(25) NOT NULL;

And there was also a view called INVENTDIMCOMBINATION which we scripted out to a query windows, deleted and recreated again. This solved the issue.

System.InvalidOperationException: The given value of type String from the data source cannot be converted to type datetime of the specified target column.

I had an issue today with the sync between Async Server and Client. Some of the jobs worked and some threw an error

Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.ProcessSourceRequestHeaderException: ProcessTargetRequestHeader failed due to an InvalidOperationException.
connectionString: Data Source=XXXXXXXX;Initial Catalog=ClientChannelDB;Integrated Security=True;Connect Timeout=60;Application Name=”Commerce Data Exchange Async Client” —> System.InvalidOperationException: The given value of type String from the data source cannot be converted to type datetime of the specified target column. —> System.FormatException: Failed to convert parameter value from a String to a DateTime. —> System.FormatException: String was not recognized as a valid DateTime.
   at System.DateTimeParse.Parse(String s, DateTimeFormatInfo dtfi, DateTimeStyles styles)
   at System.Convert.ToDateTime(String value, IFormatProvider provider)
   at System.Convert.ChangeType(Object value, Type conversionType, IFormatProvider provider)
   at System.Data.SqlClient.SqlParameter.CoerceValue(Object value, MetaType destinationType, Boolean& coercedToDataFeed, Boolean& typeChanged, Boolean allowStreaming)
   — End of inner exception stack trace —
   at System.Data.SqlClient.SqlParameter.CoerceValue(Object value, MetaType destinationType, Boolean& coercedToDataFeed, Boolean& typeChanged, Boolean allowStreaming)
   at System.Data.SqlClient.SqlBulkCopy.ConvertValue(Object value, _SqlMetaData metadata, Boolean isNull, Boolean& isSqlType, Boolean& coercedToDataFeed)
   — End of inner exception stack trace —
   at System.Data.SqlClient.SqlBulkCopy.ConvertValue(Object value, _SqlMetaData metadata, Boolean isNull, Boolean& isSqlType, Boolean& coercedToDataFeed)
   at System.Data.SqlClient.SqlBulkCopy.ReadWriteColumnValueAsync(Int32 col)
   at System.Data.SqlClient.SqlBulkCopy.CopyColumnsAsync(Int32 col, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.CopyRowsAsync(Int32 rowsSoFar, Int32 totalRows, CancellationToken cts, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.CopyBatchesAsyncContinued(BulkCopySimpleResultSet internalResults, String updateBulkCommandText, CancellationToken cts, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.CopyBatchesAsync(BulkCopySimpleResultSet internalResults, String updateBulkCommandText, CancellationToken cts, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.WriteToServerInternalRestContinuedAsync(BulkCopySimpleResultSet internalResults, CancellationToken cts, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.WriteToServerInternalRestAsync(CancellationToken cts, TaskCompletionSource`1 source)
   at System.Data.SqlClient.SqlBulkCopy.WriteToServerInternalAsync(CancellationToken ctoken)
   at System.Data.SqlClient.SqlBulkCopy.WriteRowSourceToServerAsync(Int32 columnCount, CancellationToken ctoken)
   at System.Data.SqlClient.SqlBulkCopy.WriteToServer(IDataReader reader)
   at Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.SCSqlWriteRequestRunner.BulkCopyData(SqlConnection connection, SqlTransaction transaction)
   at Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.SCSqlWriteRequestRunner.Run(SqlConnection connection, SqlTransaction transaction)
   at Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.SCSqlTargetRequestHandler.ProcessWriteRequest(SqlConnection connection, SqlTransaction transaction)
   at Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.SCSqlTargetRequestHandler.ProcessTargetRequestHeader(ISCTargetRequestHeader targetRequestHeader)
   — End of inner exception stack trace —
   at Microsoft.Dynamics.Retail.StoreConnect.Request.SQLHandler.SCSqlTargetRequestHandler.ProcessTargetRequestHeader(ISCTargetRequestHeader targetRequestHeader)
   at Microsoft.Dynamics.Retail.SynchClient.Core.DownloadAgent.ApplySessionFileToClientDatabase(SessionManager sessionMgr, String fileName)

The error turned out to be a mismatch in the configuration of the Channel Data Group where I had set the force locale to EN-UK instead of EN-US and apprently there is a difference in the date format. After changeing this parameter everything worked again.

RetailCDXMonDataSync object not initialized when processing Status Messages in AX 2012 Retail

Todays issue is regarding AX 2012 Retail…

When I try to Process status messages under Retail – Inqueries – Download sessions i get the following error


First I found some hints online that it had to do with the Working Folders set up in Retail – Setup – POS – Retail Scheduler – Channel Integration – Working Folders. I verified that the settings were OK and then I set the permissions on the folders to allow the service account for AsyncServer/AsyncClient had full access to them.

That did not help… strange… so I thought that I really needed to verify the permissions… Process Monitor to the rescue


Apparently the changes I made did not propagate all through the folder structure… After fixing it everything is working nicely.

Links:
https://community.dynamics.com/ax/b/dynamicsaxretail/archive/2016/03/13/retailcdxmondatasync-object-not-initialized-when-you-run-process-status-message

Trying to give my AX 2012 demo VM in Azure Internet Access

Today little issue was a bit frustrating…. to say the least

I have set up a new AX 2012 Vm in Azure for my colleagues to do some troubleshooting on. The need to install a Hotfix there and thus needs Internet Access from the VM. Normally this is not a problem… there are normally no issues accessing the internet from a correctly configured VM… the key phrase being correctly configured

I installed the VM from LifeCycle Services which is the normal way for AX machines which means I get a preconfigured VM with AX 2012 and it also has Active Directory installed locally to decrease dependencies. I am able to access the VM but no internet access… so I do some basic testing and I can do nslookup when using an external DNS which tells me 1) the VM has internet Access and 2) there is something wrong with the DNS settings. The local dns setting is pointing to the address is pointing to 10.20.12.4 which has nothing to do with my VM. So I tried to change it to 127.0.0.1 and as soon as I saved the settings the connection to the VM dropped… that is strange. I tried again after restarting but got the same result. So what to do…

I tried changing it using Powershell… Success!! Restarted the VM and it was back to 10.20.12.4… Fail!! Something is rotten in the state of Denmark…

I started by looking through Group policies for something strange but could not find anything. So I fired up Sysinternal Autostart and found a strange script:


Hmmm… Looking at the script:


I found it!! This is not OK!!! Well, well… I changed the script and restarted and it worked… So if your AX 2012 VM is behaving strangely look at the c:\scripts\start.ps1 script. It also fiddles with services autostart settings and some other things

/Johan

Configuring access for mobile warehousing app in Dynamics 365 for Operations

Today I am setting up the mobile warehouse app in Dynamics 365 for operation… there is a very nice Wiki article here with the walkthrough but I am doing a slightly condensed version.

  1. Go to the azure portal. In Azure Active Directory – App Registrations create a web application for the warehouse portal

    Name: WhatEverYouWant
    Application Type: Web app/API
    Sign-on URL: https://[theURLforyourdynamicsinstance]/oauth

  2. Open the application to edit it
  3. Verify Application ID. If you create the Application in the new new portal it will auto generate an AppID which is random. If you use the old portal to create the application you will have to add the App ID URI. Make sure that this URI is NOT your Dynamics 365 for operations URL because this will break for instance Excel Add-in and Management Reporter. For more information look here
  4. Note: the next step did not work from the new portal so I had to perform it from the old portal.
  5. Go to the old Azure Portal – Active Directory – [Your AD] – Applications and select the application you created in the previous step
  6. Under Permissions to other applications click add application and add Microsoft Dynamics ERP
  7. Add the following permissions

    Access Dynamics AX online as organization users
    Access Dynamics AX data
    Access Dynamics AX Custom Service

  8. In the new portal in the application permission click keys, enter the name for your new key and set a duration. When you click save you will get the key. Please remember to copy and save it some where because it will not be visible later.
  9. Now you need to save the ClientID (Old Portal)/Application ID (New Portal) for later.
  10. Log into Dynamics 365 for Operations and go to System Administration – Users and create a new user (in my case called WMAPP. The email address can be anything since it will never be used. The user needs these roles

    Warehouse mobile device user

  11. Now we need to associate the user to the AD Application which is done on System Administration – Setup – Azure Active Directory applications. Here we paste the App ID/ClientID from before and select the user we created. Click Save and you are done.
  12. Install the App from app store and enter these settings:

    SNAGHTML12dda1b

    1. Azure Active Directory ID: AppID/CleintID from step 9
    2. Azure Active Directory Client Secret: The key from step 8
    3. Azure Active Directory Resource: Your Dynamics 365 URL
    4. Azure Active Directory Tennant: https://login.windows.net/yourADtennant
    5. Company: Dynamics 365 for Operations Legal Entity

Links:
https://ax.help.dynamics.com/en/wiki/install-and-configure-dynamics-365-for-operations-warehousing/

Changing the certificate used for Channel database sync in AX 2012 Retail

I have been trying the past couple of bays to get retail up and running on the Microsoft Dynamics AX 2012 R3 demo environment. There are some issues in the default environment that needs to be fixed before everything is running flawlessly.

One issue I noticed was that the SSL certificate used between the async client and async server has expired (in 2015 Smile ).


To fix this we first need to request and issue a new certificate. Since the CA in the Demo is a stand-alone CA we cannot use the MMC to request the certificate, so I am using the web interface. Start Internet Explorer and browse to the address https://localhost/certsrv (since the certificate for the site is not issued to localhost there will be an error… ignore this).


Select Request a certificate


Select advanced certificate request


Select create and submit a request to this CA


Click Yes to continue


Fill in the name of the certificate. In our case the adress is retail.contoso.com, the other fields are not mandatory. Select Server Authentication Certificate and check  Mark keys as exportable. Click Submit.


Note the id of the request and start the Certificate Authority mmc Management Console


Find the request above under Pending Request. Right-click and select the task Issue


Go back to https://localhost/certsrv and click View the status of a pending certificate request. Click your request.


Click Yes to continue.


Click the Install this certificate. Unfortunately the certificate will be installed in you personal Certificate Store and you will have to move it before IIS can use it.


Start the management Console and add the Certificates snap-in for Current User and for Local Computer. Go to Current User – Personal – Certificates and find your new certificate


Right click the certificate and select Export


Select Yes, export the private key


Check Export all extended properties and click next


Enter a password and click next


In the console on Local Computer – Personal – Certificates right click and import the Certificate you exported previously

          image     image

In IIS Manager edit Binding for the sites AsyncServerSite and Retail Server Website and change the certificate for HTTPS. Restart the IIS sites.

That is all

/Johan
